BCF Spinning Machine

Using PA6, PET, and PP as raw materials, BCF Spinning Machine adopts the one-step process of spinning, drafting, and deformations to produce BCF yarn; PP raw materials can be added recycled materials, reduce the cost and PET raw material can be used in 100% bottle flakes.

PP fiber is the quality with the greatest development potential among the four major synthetic fibers, and it is already the second-largest synthetic fiber variety. Polypropylene can be divided into staple fiber, filament, non-woven material, tobacco tow, bulk continuous filament, and so on.

What is BCF Spinning Machine



BCF is a bulky continuous filament from a filament extrusion line . The production routes can be divided into the following three types:

One-step method: continuous spinning, drawing, texturing, winding process
Three-step method: combined spinning and stretching, combined yarn deformation or spinning and winding, combined yarn stretching and deformation
Two-step method: Spinning is the same as conventional spinning, one winding bobbin has one color, and then three bobbins of different colors are combined and stretched or deformed into BCF.

Technical Specifications of BCF Spinning Machine



Material	PP PET PA6
Denier(D) Range	600-3600
Mechanical speed	2800m/min
NO. of Positions	2/3 positions(customized)
Hot Godet Dimension	φ220mm
Extension Texturizer	Friction blade type or non-sheet type texturizer
Winders	Automatic

Performance and Advantages



The combination of spinning, drawing, winding, and other modular equipment, to produced monochrome, carpet yarn; Equip the weight colour dosing system to ensure the unification of the colour.
New screw, barrel, special process design, suitable for the production of a variety of polymers.
The specially designed expanded spin pack is used to ensure the uniform distribution of spinning melt, flow smoothly.
A special rotary expanded conponent to improve the stability of BCF yarn.
Specially designed monomer suction system can discharge oligomer and lactam.
A new type of nozzle type changing device, and the optimized cooling drum between the coordination, to ensure excellent curl shaping.
The hot goldets use synchronous motor, high frequency heating, imported temperature control transmitter, to ensure the temperature.
With automatic winder system, the yarn tension is constant, with good transfer, yarn shape is excellent.

Application



The main application of PP polypropylene fiber is in the two fields, non-woven fabric, and carpet yarn. The application of PP fiber in carpet yarn is mainly in the form of BCF Yarn.
